ModuMed modular medical cabinet system
Excellent hygiene:
Features an antimicrobial coating (ISO 22196 certified) and seamless design to protect against pathogens and harsh disinfectants, ensuring compliance with medical sterilization standards.
Full customization:
Supports custom sizes, modular internal organization (adjustable shelves/drawers) and additional options such as locking drug compartments or built-in power supplies.
Medical Grade Durability:
Made of 304 stainless steel or electrolytic steel, providing high load capacity (50kg/shelf) and long-term reliability (more than 10,000 working cycles).
Product overview
The ModuMed modular medical cabinet system is a customizable storage solution designed for healthcare environments that require strict hygiene and efficient space organization. Constructed from high quality 304 stainless steel or antimicrobial coated electrolytic steel, these cabinets support dynamic designs for surgical instruments, medications and sterile supplies. Standard modules have widths from 600 to 2000 mm, depths from 500 to 800 mm and heights from 650 to 1020 mm, all sizes can be customized to suit customer requirements. Compliant with ISO 13485 standards and FDA guidelines, they are easily integrated into hospitals, laboratories and clinics.
Key Benefits
1. Hygienic surface protection
Electrolytic steel surfaces with an ISO 22196 certified antibacterial coating inhibit the growth of microorganisms (99.9% reduction for MRSA and E. coli).
Seamless welds and rounded corners prevent contamination build-up, allowing for easy disinfection with harsh chemicals such as hydrogen peroxide.
2. Structural durability
1.2mm thick stainless steel cores withstand loads of up to 50kg per shelf (tested to EN 1021-1/2).
Heavy-duty hinges and drawers are rated for over 10,000 cycles, making them ideal for high-traffic areas in clinical settings.
3. Flexibility of individual solutions
Possibility of changing sizes, door styles (sliding/glass/steel) or interior layout with adjustable shelves, dividers and ABS plastic medical trays.
Additional specialized functions:
IV holders
Integrated sockets
Lockable compartments for narcotics
4. Space optimization
Built-in or mobile designs (with locking casters) make optimal use of space in operating rooms, intensive care units and pharmacies.
Functional features
Modular shelving system:
Adjustable shelves and dividers (in 50–200 mm increments) allow you to place various consumables, from infusion bottles to endoscopic instruments.
Controlled access:
German locks with a 3-point locking mechanism ensure the protection of sensitive items.
Ergonomic design:
Soft-close drawers and silent rollers reduce noise levels during night shifts.
Lighting and visibility:
Optional LED lighting improves visibility in low-light conditions.
Areas of application
Operating rooms: Storage of sterile instruments and anesthetics with traceability.
Intensive Care Units: Mobile cabinets for quick access to emergency medications and supplies.
Laboratories: Chemical-resistant surfaces protect reagents and sensitive equipment.
Pharmacies: Modular drawers with dividers for organizing tablets, syringes and vials.
Specifications
| Options | Characteristics |
| Compliance with requirements | ISO 13485, EN 60601-1, FDA 21 CFR Part 211 (GMP) |
| Material | Stainless Steel 304/Electrolytic Steel (SGS Certified) |
| Surface finishing | Electropolishing + Antimicrobial coating (colors according to the RAL catalog) |
| Load capacity | 50 kg/shelf (static), 25 kg/box |
Why choose ModuMed?
30% Faster Installation: Pre-drilled components and digital assembly instructions reduce installation time.
Cost-effectiveness: Reconfigurable modules eliminate the need for complete replacement when upgrading premises.
