Passageway in the wall

Product description

The Self-Cleaning Transfer Chamber is a state-of-the-art module for material transfer in cleanrooms with integrated self-cleaning and UV sterilization functions. Ideal for industries with ultra-high cleanliness requirements. This self-cleaning transfer chamber uses a combination of high-intensity UV light and controlled airflow to remove airborne particles before and after each transfer cycle.

Specifications / Parameters

Material: Highly polished stainless steel interior and exterior

Lock Type: Hybrid Mechanical/Electronic Dual Door System

Glass: 5mm tempered glass for shock resistance

Sterilization: Built-in UV lamp and internal air circulation with HEPA filter

Door type: Swing door with silicone sealing strips

Sizes: Standard and custom sizes available

Applications: Biotechnology, aerospace, precision optics

Advantages

• Integrated self-cleaning system – Keeps the interior surface free of dust without manual intervention.

• Dual Sterilization Method – Combines UV light and HEPA filtration for maximum contaminant control.

• Seamless Interior Design – Rounded corners prevent particle build-up.

• General Purpose - Suitable for critical areas.

Design and components

• Stainless steel body with anti-scratch coating

• Locking control mechanism (hybrid type)

• UV germicidal lamp with automatic shut-off when the door is opened

• HEPA filter module with low-noise fan

• Internal airflow system for self-cleaning cycles

Application

Handling high-precision optical lenses in clean rooms

Transport of sterile laboratory samples in pharmaceutical R&D

Transfer of surgical instruments between sterile operating rooms

Maintenance and precautions

Replace the HEPA filter every 12-18 months depending on usage.

Clean glass and stainless steel surfaces weekly.

Check the operation of the UV lamp monthly

Keep the internal airflow vents clear for optimal self-cleaning system operation.
